Lippage Between Vinyl Planks After Installation: Why One Edge Sits Higher, and How to Fix It

A plank edge standing proud of its neighbor catches light, feet and cart wheels. On vinyl it usually means a joint that is not fully locked, a bump underneath, or a glued plank that never bonded flat.

In short

On vinyl plank, a raised edge usually means a joint that never fully locked; Timeless lists a peaked appearance and ledging among the results of improper locking.1 Unevenness or debris in the subfloor can telegraph through.1 On glue-down floors, guides call for rolling with a 100 lb roller and rolling again if needed.2 The fix depends on which it is.

Lippage is the word tile setters use for a height difference between neighboring pieces. The term travels well to vinyl plank. One plank edge sits slightly above the next, the seam catches the light from a window, and a sock or a cart wheel catches on it. On a new floor it looks like poor workmanship. Sometimes it is. Often it is a joint, a substrate or an adhesive problem that the installer can trace and correct.

Why it matters

A raised edge is more than cosmetic. Writing about tile in The Construction Specifier, the consultant Donato Pompo notes that excessive lippage can cause trip-and-fall incidents, particularly for people who shuffle or use walkers.3 He adds that in commercial settings, carts and equipment clack as they run over raised edges.3 A raised vinyl edge also takes the wear first. Timeless Designs warns that unevenness in the subfloor can telegraph through and cause excessive wear on high spots.1 In healthcare, schools and offices with rolling loads, an edge that stands up is a maintenance issue and a safety one.

Hammers, scissors and other hand tools hanging on a workshop wall
FIG 01Hammers and other hand tools hanging on a workshop wall.Photo: cottonbro studio, via Pexels

A joint that is not fully locked

On click-lock floors this is the most common cause. A long side or short end that has not fully seated leaves one plank riding on the other's profile. Timeless lists the results of improper locking: distressed joints with a peaked appearance, delamination due to ledging, separation of joints and side joint failures.1 National Flooring Products warns that a row can appear to be engaged but is not. It asks installers to tap the short side and then the long side together with a tapping block.4

The check is simple. Press down on the raised edge. If it drops and stays, the joint was sitting on its lock and has now seated. If it springs back, the profile is damaged or something is under it. Timeless also warns that poor acclimation can leave joints difficult to properly engage.1

Debris and a damaged profile

A chip of core or a grain of grit in the groove holds the joint open by a fraction of a millimeter. National Flooring Products asks for all edges to be inspected and cleared of debris before installing.4 A profile cracked during installation will not pull flat at all; see end joints breaking during install. In both cases, the plank has to come out. A cracked one must be replaced.

Wood parquet blocks laid in a basket-weave pattern
FIG 02Wood parquet blocks laid in a basket pattern.Photo: Ivan Vi, via Pexels

A bump underneath

A ridge in the substrate pushes one edge up wherever a seam crosses it. Timeless says roughness or unevenness of the subfloor may telegraph through to the flooring.1 Common causes are a trowel ridge in patching compound, a seam in the subfloor panels, a screw head or a lump of drywall mud. The guides set limits on flatness, and Marquis asks for the subfloor to be within 3/16” in 10’ or 1/8” in 6’.5 A short, sharp bump can be within that tolerance and still lift a seam. Elite asks for high spots to be ground down.6 See the flatness guide and subfloor seams telegraphing.

Glue-down planks that never bonded flat

On adhered floors, lippage is usually an adhesive or rolling problem. EverStep's glue-down instructions say the adhesive must transfer to the floor product to ensure a proper bond. After installation, the floor is rolled and cross-rolled with a 100 lb sectional roller.2 Areas the roller cannot reach get a hand roller, and the installer checks again after 1-2 hours and rolls again if necessary.2 Daltile lists a 100 lb roller and a hand roller among the tools for its glue-down LVF.7

Adhesive timing matters too. Armstrong explains that flooring placed into adhesive after its working time has passed will not bond.8 A plank that never bonds can curl at its edges, and its neighbor ends up lower. See glue-down bubbles and adhesive mistakes.

Low view across textured rustic wood planks
FIG 03Rustic wood planks, seen low across their surface.Photo: James Frid, via Pexels

Real and perceived lippage

Pompo makes a point that applies to vinyl too: some complaints are about perceived lippage, caused by lighting design rather than real height differences.3 Low-angle light from a window or a corridor wall-washer exaggerates the smallest edge. Before tearing up planks, measure. A straightedge or a feeler gauge across the seam shows whether there is a step. If there is none, the fix is lighting or expectations.

How much is too much

Tile has published lippage allowances. The vinyl installation guides in our sources do not set a number; they rely on flatness limits and fully engaged joints instead. That leaves the judgment to the contract and the people on site. Pompo argues that excessive lippage is best avoided with specifications that include quality testing, mockups and quality control.3 He traces most excessive lippage to a mix of poorly prepared substrates, improper methods and materials, and poor workmanship.3 For a commercial vinyl floor, the practical standard is that a seam is flush to the touch, and that no edge catches a cart wheel. Agree on that before the job, not at the punch walk.

Fixes, by cause

CauseFix
Joint not seatedTap the joint closed with a scrap over the seam, or press per the guide
Debris or cracked profileUnlock back to the plank, clean or replace it
Bump in the substrateLift the planks, grind or fill, relay
Glue-down not bonded flatRe-roll if the adhesive allows; otherwise replace the plank
Perceived onlyMeasure, then address lighting

When tapping, protect the profile. Timeless says to place a scrap over the end joint and tap lightly, never striking the plank directly.1 When a plank has to come out mid-floor, see replacing a single plank.

Preventing it on the next job

Check the substrate with a straightedge before the first plank goes down, and clean it. Keep cut dust away from the working edge. Close every joint the way the guide describes, then walk each row before starting the next. On glue-down jobs, roll on schedule and recheck. On commercial work, run a small mockup where specified, so everyone agrees what a flat seam looks like before the whole floor goes in.

Dark wood planks with tight joints and visible grain
FIG 04Dark wood planks with tight joints.Photo: Nikolaos Dimou, via Pexels

Sources

  1. Timeless Designs, “Click Floating Luxury Vinyl Installation Instructions”. timelessdesignsflooring.com/wp-content/uploads/2023/05/TD-Rigid-Core-Ins
  2. EverStep Flooring, “LVP Glue Down Installation Guidelines”. everstepflooring.com/technical/lvp-glue-down-installation-instructions/
  3. The Construction Specifier, “Tile and stone lippage: What is acceptable (and how do you specify it?) - Page 2 of 2 - Construction Specifier”. constructionspecifier.com/tile-and-stone-lippage-what-is-acceptable-and-
  4. NFP, “Architect’s Choice LVP Installation Guide”. my-nfp.com/resource/architects-choice-lvp-installation-guide
  5. Marquis Industries, “Rigid Vinyl Plank Installation Instructions (Angle)”. marquisind.com/static/resources/Angle_Angle%20Installation%20Instruction
  6. Elite Flooring, “Välinge Installation Guide (Woodlands)”. eliteflooringusa.com/links/install-instructions/Elite-Installation-Guide
  7. Daltile, “ProSeries Luxury Vinyl Flooring Installation & Care Guide (Rigid Core Click, Glue Down)”. s1.img-b.com/build.com/mediabase/specifications/daltile/1996309/daltile-
  8. Armstrong Flooring, “Adhesives FAQs”. armstrongflooring.com/commercial/en-us/resources/flooring-faqs/adhesives

General information for the flooring trade. This article was drafted with AI assistance and checked against the sources listed above; the manufacturer's current instructions and the project specification govern any real job. If something here is wrong or out of date, tell us.
