Fully Adhered Homogeneous Sheet Vinyl: The Prep, Adhesive and Seam Sequence Behind a Healthcare Floor

On healthcare and education bids, the heat-welded seam gets the attention. The Construction Specifier calls heat welding a common and critical component of a typical healthcare flooring installation.² The weld still comes last. The same article says a misaligned sheet creates a cascading series of issues that affect grooving, welding and skiving.² The weld inherits every earlier mistake.

The Resilient Floor Covering Institute publishes the earlier steps as its recommended installation practice for fully adhered homogeneous sheet. That practice establishes minimum procedures, and specific recommendations from the product's manufacturer may change it.¹ Treat it as the floor beneath the manufacturer's instructions, not a replacement for them.

Job conditions before the sheet is unrolled

Storage problems start on delivery. RFCI says homogeneous sheet must be tightly rolled face out on a sturdy core and stored vertically, or as the manufacturer recommends.¹ If the material was flattened or distorted in storage or transport, RFCI says not to install it.¹ Upright storage has its own risk. The Construction Specifier notes a vinyl roll can weigh well over 250 lb, and that weight can compress the edge resting on the floor.² Pens, felt-tipped markers and waxed crayons must not be used on the backing or for layout on the under floor, because they could bleed through and stain.¹

RFCI also sets environmental conditions:

• A permanent HVAC system must be operational before installation.¹
• Flooring, accessories and installation products stay at room temperature, min. 65°F and max. 100°F, for at least 48 hours before, during and after installation.¹
• With reactive adhesives such as epoxies, room temperature should not exceed 85°F during installation.¹
• Afterward, temperature should be maintained above a minimum of 55°F.¹
• Excessively high or low relative humidity affects patch curing and adhesive open times, and those conditions should be avoided.¹
• Homogeneous sheet is intended for interior locations only.¹

On a renovation wing where the air handlers are still being commissioned, the HVAC requirement alone can move the flooring start date. Raise it at the schedule meeting, not on the day the crew arrives.

The substrate: tests that must be documented

RFCI says moisture testing must be conducted on concrete and names ASTM F1869 and ASTM F2170 as the common tests.¹ It gives generally acceptable ranges of 3.0 lb. MVTR or below for F1869 and less than 75% RH.¹ Documented moisture and pH testing must be conducted on all concrete substrates, regardless of grade level.¹ ASTM F710 agrees that all slabs should be tested for moisture regardless of age or grade level, and all concrete floors for pH.³ F710 also requires a permanent, effective moisture vapor retarder under all on- or below-grade concrete floors.³ Neither document overrides the manufacturer. F710 states it does not supersede the flooring or adhesive manufacturer's written instructions.³ For test methods and manufacturer limits, see concrete moisture testing and slab pH.

Bond tests, as recommended by the flooring manufacturer, also need to be performed and documented before work starts.¹ RFCI says cracks should be patched with an appropriate patching or leveling compound.¹ All dirt, wax, dust and other substances must be removed, and fasteners must be secure and set flush.¹

RFCI lists under floors where homogeneous sheet should not go, including:

• Asphalt tile, asphalt-based adhesive, or surfaces with any type of residual adhesive.¹
• On-grade or below-grade concrete subject to excessive moisture or hydrostatic pressure.¹
• Loose-laid or perimeter-fastened floor covering, self-stick tile and existing cushioned resilient flooring.¹
• Strip-wood or plank under floors.¹
• Radiant-heated floors with surface temperatures greater than 85°F.¹

The residual adhesive line is where bids lose money. Existing resilient floors with irregularities or deep embossing must be covered with a minimum 1/4 inch underlayment or an embossing leveler; otherwise RFCI says they must be removed.¹ Ceramic tile must be overlaid with a cementitious latex patching compound, fully cured before the sheet goes down.¹ Wood subfloors must be double-layer construction, suspended at least 18 inches above grade, with adequate cross-ventilation.¹

Removal carries its own warning. RFCI says not to sand, dry-sweep, dry-scrape or mechanically pulverize existing resilient flooring or adhesive, because these products may contain asbestos or crystalline silica.¹ Unless positively certain otherwise, you must presume the material contains asbestos.¹ If mold or mildew turns up during removal or installation, RFCI says flooring work should stop until the mold and any related moisture problem are addressed.¹

RFCI's layout drawing includes a notation of who is responsible for preparation or removal of the existing floor.¹ If that line is blank at bid, the dispute happens after the scrape crew finds cutback. Put the answer in writing, or price it as a change order before work starts.

Layout and seam placement

RFCI says seams should be positioned so main traffic runs parallel to them, light does not strike directly across them, and they stay away from pivoting traffic.¹ In doorway openings between rooms, parallel seams are required.¹ The end user should see the layout, including intended seam locations, and approve it before installation.¹ RFCI calls a minimum 2-3% of additional material as attic stock common practice.¹ For areas with concentrated static or rolling loads, RFCI recommends a hard-set adhesive.¹

Adhesive, open time and rolling

Once the sheet is unrolled and cut to fit, RFCI says it should be completely installed within four hours.¹ Sheets go down reverse or non-reverse as the manufacturer recommends.¹ With the sheets positioned, fold them back to expose the under floor.¹ If the manufacturer recommends it, seam adhesive goes down in a 3 to 6 inch wide band centered under the seam.¹ Field adhesive follows over 100% of the remaining exposed under floor, using the recommended notched trowel.¹

After sufficient open time, the straight-edged sheet goes into the adhesive first, then the second sheet.¹ RFCI says to roll to within about 6 inches of the seam line with a 100 lb. three-section floor roller, then repeat for the other half.¹ Open time is not a fixed number. RFCI says it depends on subfloor porosity, room temperature, relative humidity and the amount of adhesive applied.¹ Those are the variables that shift between a dry corridor and a freshly patched patient room.

The recess-scribed seam

RFCI says typical homogeneous products require seams cut by recess scribing.¹ The selvage edge of one sheet is straight-edged or trimmed approximately 3/8 inch from the edge.¹ The top sheet then overlaps that prepared edge by approximately 1/2 inch.¹ Set the scriber for a net fit, not gapped or too full, and do not set the needle too deep or force the cut.¹ After cutting, roll the seam with a hand seam roller to level the edges, then re-roll the whole area with the 100 lb. roller.¹ Clean the seam area and wipe it dry.¹

The Construction Specifier describes some of the same steps with different figures. Where they differ, the manufacturer's written instructions decide.

Step	RFCI practice	Construction Specifier article
Edge trim	Approximately 3/8 inch from the selvage 1	Roughly 0.5 in. as best practice 2
Seam fit	Net fit, not gapped or too full 1	Manufacturer's spacing, typically around 1/32 of an inch 2
Groove depth	Typically two-thirds of thickness, approximately 0.050 inches 1	Most manufacturers specify half to two-third deep 2
Trimming the rod	Two steps, spatula knife and trim plate first 1	Two passes, the first removing half to two-thirds of the excess 2

The wait, the groove and the weld

RFCI says seams must be heat welded.¹ It says to wait at least 24 hours after installation, so the adhesive can cure, before grooving.¹ The groove should have a centered U shape.¹ Heat welding always depends on speed and temperature, and RFCI says to practice on scrap to find both.¹ If the manufacturer recommends it, the trimmed rod may be glazed with heat or a topical sealer to reduce its porosity.¹ Weld technique and seam failures are covered in heat-welded seams that open later.

Edges need attention too. RFCI recommends covering all exposed edges.¹ Where molding is not feasible, such as at floor drains, RFCI says to use a reactive hard-set adhesive such as epoxy or polyurethane.¹ Coved rooms use cap molding on the wall.¹ For the cove itself, see flash cove details and choosing cove base.

After the last seam

RFCI says to use the floor as little as possible for at least 24 hours, to minimize indentation while adhesive sets.¹ It does not recommend heavy furniture or rolling loads for at least 72 hours.¹ If other trades work in the room, protect the floor with heavy non-staining paper or similar material.¹ Castors and glides should keep static loads under 250 psi.¹ On a fast-track hospital fit-out, the 24-hour grooving wait and the 72-hour restriction belong in the schedule from day one.¹ See floor protection rules.

What to ask, check and put in writing

• Which manufacturer instructions override RFCI's minimums, and for which steps.¹
• Documented moisture, pH and bond test results for every concrete area, regardless of grade.¹
• Who removes residual adhesive and existing flooring, and under what asbestos protocol.¹
• Permanent HVAC running, with the 48-hour conditioning window met.¹
• Seam layout approved by the end user before cutting.¹
• Edge trim, net-fit and groove depth figures from the manufacturer, not memory.^{1 2}
• Grooving held at least 24 hours after installation.¹
• No rolling loads for at least 72 hours, agreed with the general contractor in writing.¹
• A signed job completion ticket at closeout.¹
