Photographing Flooring for Warranty Claims: What to Shoot, When, and Why the Record Starts Before Installation

When a floor fails, three parties usually point at each other: the manufacturer, the installer and the site. The manufacturer's inspector looks for evidence that the product was faulty or that it was installed or maintained outside the instructions. The answer usually depends on what can be shown about conditions on the day the floor went in. Photos are the cheapest evidence there is, if they were taken at the right time.

Start before the floor goes down

Paul Pleshek, a flooring inspector writing in Flooring Contractor magazine, says he inspects every job on the assumption that it will be litigated.¹ His advice to installers is the same. The simplest and most effective way to avoid being wrongly blamed for a failure is photo documentation of every step of the installation.¹ He sets out what to shoot, in order.

The photo list, step by step

1. The site on arrival. Photograph the exterior conditions. They prove what the site looked like if it is later altered.¹
2. The rooms before removal. Where possible, photograph rooms before existing materials come out. Problem areas tend to return on the new floor, and the old floor's damage can show a site condition.¹
3. Acclimation and readings. Record how long and where the material acclimated. Photograph temperature, relative humidity, surface temperatures, data loggers and subfloor moisture tests.¹
4. Subfloor and preparation. Show the substrate construction, how flatness was checked, and the materials used to fix high and low areas, sealers and moisture mitigation. Test again after prep and photograph the results.¹
5. The material itself. Photograph carton end stamps or back labels on the flooring, cushion, pad and barriers. That confirms the product is as ordered and whether the shipment is from one manufacturing lot.¹
6. The finished floor. Photograph the overall appearance, and the floor in reflected light. Take close-ups of traffic areas, where discoloration, scratches and gouges may be reported weeks later.¹

Pleshek points out that the readings matter most for moisture claims. They separate conditions at installation from daily conditions afterward. That is especially important in new construction, where climate control may be inconsistent during finishing.¹

Defects you can see before installing

Visible defects are handled differently from hidden ones. Mohawk's residential vinyl plank warranty makes it the installer's or end user's responsibility to confirm that received material is free of obvious visible conditions.³ Marquis says materials with visible defects are not covered under warranties once they are installed.² VPI's rubber tread instructions say claims for surface defects or color and pattern variation must be made before the material is installed.⁴

The rule for the crew is simple. If a plank, tile or roll looks wrong, stop, photograph it with its carton label, set it aside and call it in. Installing it usually means accepting it. Interface asks for a benchmark area to be inspected by all authorizing parties, and for discrepancies to be reported before the rest is installed.⁵ Its example is 100m2.⁵

How to take the pictures

• Wide, then close. One photo that shows where in the room, then one that shows the detail. A close-up with no context proves little.
• A scale in the frame. A tape measure or ruler beside a gap, a crack or a stain shows its size.
• Meter readings in focus. Photograph the display with the meter in place, so the reading and the location are in one image.
• Low-angle light. Shoot along the floor toward a window for seams, peaking and lippage. Shoot straight down for color.
• Keep the metadata. Phone photos carry date and time. Send originals, not screenshots or compressed copies.

After a failure

When a complaint comes in, photograph before anyone touches the floor. Then record the readings again: room temperature and humidity, surface temperature, moisture in the substrate where it can be reached. Note what has changed since installation. New furniture, rugs, mats, cleaning products, or a change in the building's HVAC schedule are all relevant. Mohawk notes that it may send an inspector to determine unknown causes, at its discretion.³

An inspection is only as good as its evidence. Lewis Migliore, a commercial flooring consultant writing for Facilitiesnet, describes a vinyl plank claim initially blamed on installation as too tight. Lab testing later showed a manufacturing defect, and attic stock still in its boxes revealed further problems.⁶ Keep sealed attic stock. It is a sample of what was delivered.

Paperwork the warranty expects

Photos sit alongside documents, and the warranty usually says which ones. Mohawk's vinyl plank warranty reimburses reasonable labor costs, up to 100% in years 1 and 2, based on a detailed statement, if professional installation was paid for originally.³ If it authorizes a repair, the owner must clear any items placed over the affected area after installation, and Mohawk will not pay for that removal.³ Its warranty also excludes consequential damages, meaning losses beyond the flooring itself.³ So keep the installation invoice, and photograph what has been built or placed on the floor since. Those two records shape what a successful claim actually pays.

Keep a job file

Pleshek's closing advice is to assemble a file for each job.¹ Organize it by step: site, prep, readings, material labels, finished floor, and any later complaint. Put the installation instructions in it, the warranty document, the delivery tickets with lot numbers, and the maintenance instructions handed over at closeout. Pleshek says the documentation takes very little time and is virtually free.¹ It also makes the claims process clearer for consumers, retailers, manufacturers and inspectors.¹ For the delivery step in detail, see inspecting flooring deliveries.

Sources

1. Flooring Contractor magazine, “Inspector Input (Winter 2019)”. digitaladmin.bnpmedia.com/publication/
2. Marquis Industries, “Rigid Vinyl Plank Installation Instructions (Angle)”. marquisind.com/static/resources/Angle_Angle%20Installation%20Instruction
3. Mohawk (via Lowe's), “LVT/LVP Residential Limited Warranty”. pdf.lowes.com/warrantyguides/842374006031_warranty.pdf
4. VPI Corporation, “Tread, Riser and Nosing Installation and Maintenance”. vpicorp.com/downloads/1P%20-%20Install%20&%20Maint%20Tread-Riser-Nosing%
5. Interface, “Carpet Tile Installation Instructions”. interface.com/content/dam/interfaceinc/interface/technical/emea/installa
6. Facilitiesnet, “How to Handle Flooring Claims”. facilitiesnet.com/flooring/Contributed/How-to-Handle-Flooring-Claims--43

General information for the flooring trade. This article was drafted with AI assistance and checked against the sources listed above; the manufacturer's current instructions and the project specification govern any real job. If something here is wrong or out of date, tell us.
